STAGE 2

Toyota Landcruiser 200

Braked Towing Capacity Upgrade

Stage 2 Kit- Recommended for towing 3500kg-4000kg Apparatus.

Kit includes height adjustable drop shank and Lovells All Terrain Haul Ace Coupling/Hitch system plus a Lovells 1200lb Weight Distribution Hitch system (WDH).

(Ball weight must not exceed 400kg).

​

Please note that the Lovells BTC Upgrade can only be complied if a Lovells GVM Upgrade is fitted to the vehicle.

​

Lovells BTC Upgrade tongue/hitch receiver/drop shank can only be attached to the Toyota OE Towbar and is not compliant for aftermarket tow bars.

​

Kit Includes:​

  • Weight Distribution Hitch system (WDH)

  • 95mm height adjustment drop shank

  • Cast head assembly

  • Lovells Haul Ace Hitch

  • Secondary Manufacturer Compliance Plate

​

IMPORTANT - A Lovells Braked Towing Capacity (BTC) upgrade can only be fitted to a vehicle in conjunction with a Lovells GVM upgrade. The BTC upgrade can be fitted to the following Lovells GVM upgrade products

STAGE 1

Toyota Landcruiser 200

Braked Towing Capacity Upgrade

There are two BTC upgrades available for the LC200, these are Stage 1 and Stage 2.

Stage 1 Kit- Recommended for towing 3500kg-3700kg Apparatus.

Kit includes height adjustable fabricated tongue and Lovells All Terrain Haul Ace Coupling/Hitch system. This kit is however still rated at 4000kg braked towing capacity. (Ball weight must not exceed 350kg)

​

Not compatible with most weight distribution systems.

​

Kit Includes:

  • Dual height adjustable fabricated tongue

  • Hitch System

  • Secondary Manufacturer Compliance Plate

​

IMPORTANT - A Lovells Braked Towing Capacity (BTC) upgrade can only be fitted to a vehicle in conjunction with a Lovells GVM upgrade. The BTC upgrade can be fitted to the following Lovells GVM upgrade products

KEY ADVANTAGES OF FITTING A

LOVELLS BTC UPGRADE

  • The BTC Upgrade kit is Approved by the Department of Infrastructure, Transport, Regional Development and Local Government and comes complete with a secondary manufacturers compliance plate or State Transport Compliance.

  • Lovells BTC Upgrades can be complied prior to registration on Federal Compliance OR certified under State Compliance for already registered vehicles.

  • Keeping you legal- The Upgrade kit is legal in all States and Territories. Protects Business and Fleet Managers from claims and breaches of OH&S rules and employee negligence if towing beyond the vehicles limits.

  • Protects you from Insurance companies voiding payout if the vehicle is towing beyond approved Braked Towing Capacity.

  • Removes the possibility of fines or litigation if is vehicle operated beyond its legal Towing Limits.

  • Australian designed and made.

  • Easily hitched and disconnected, even on uneven ground.

  • Easy to operate. One person hitching.

  • Anti theft Hitch locking mechanism.

  • No tools needed to hitch or unhitch.

  • Automatic hitch locking feature.

  • Low maintenance and fully sealed from dust and dirt.

  • Designed for hardcore offroad use or highway use.

  • Hitch rated at 5 Tonnes

  • WDH Anti- Sway System rated at 544kg

  • Less than 2 hours to fit and comply

  • Authorised Fitters and Spares available nationwide
